ZZ572/620 Engine - GM (19331583)

19331583

ZZ572/620 Engine - GM (19331583)

19331583

Not for Sale

No Longer Available For Purchase

Manufacturer Warranty Minimum of 12 Months
Guaranteed Fitment Always the correct parts
Shop with Confidence Your information is safe
In-House Experts We know our products
  • Details
  • Also Purchased
  • Additional Info
  • Vehicle Fitment
  • Product Reviews
  • Ask Our Team
  • Warranty & Disclosures
  • Installation Instructions
  • Policies

Details

  • Brand:
    Buick, GMC, Cadillac, Hummer, Saturn, Oldsmobile, Pontiac, Chevrolet Parts
  • SKU: 19331583
  • Other Names: ENGINE
  • Description:

    THE MOST POWERFUL BIG-BLOCK STREET ENGINE FROM CHEVROLET PERFORMANCE

    The ZZ572/620 is the ultimate expression of Chevrolet Performance’s engineering capability.

    We build the ZZ572 with huge 4.560-inch bores and add a forged 4.375-inch-stroke crankshaft. To make sure those cylinders are packed with every cubic centimeter’s worth of atmosphere, we use a camshaft with incredible 0.632/0.632-inch lift and 254°/264° duration specifications.

    Aluminum rectangular-port heads with 310-cc intake passages complement the airflow capability offered by the big-bore bottom end. They also feature 118-cc raised exhaust ports and 118-cc combustion chambers. The valves are big, too — measuring 2.250 inches on the intake side and 1.880 inches on the exhausts.


    Chevrolet Performance delivers the ZZ572/620 Deluxe with an 850-cfm carburetor, HEI distributor, aluminum water pump, and distinctive orange powder-coated valve covers that proudly proclaim the 572 legend.

    For the builder who wants the foundation of this Big-Block powerhouse, but wants to finish it with the induction system of his choice, we offer the ZZ572/620 Base engine P/N 12498792. It comes with the bottom end fully assembled — including the forged crankshaft, rods, and pistons — along with the unique 0.632-inch-lift roller camshaft.

    ZZ572/620 DELUXE TECH SPECS

    Part Number:
    19331583


    Engine Type:
    Chevy Tall Deck Big-Block V-8
    Displacement (cu. in.):
    572
    Bore x Stroke (in.):
    4.560 x 4.375
    Block (P/N 19212195):
    Cast-iron with four-bolt main caps
    Crankshaft (P/N 88961554):
    Forged steel
    Connecting Rods (P/N 88962926):
    Forged steel, shot peened
    Pistons (P/N 88962925):
    Forged aluminum
    Camshaft Type (P/N 19210721):
    Hydraulic roller
    Camshaft Lift (in.):
    .632 intake / .632 exhaust
    Camshaft Duration (@.050 in.):
    254° intake / 264° exhaust
    Cylinder Heads (P/N 12499255):
    Aluminum rectangular port, 118-cc chambers
    Balanced:
    Internal
    Valve Size (in.):
    2.250 intake / 1.880 exhaust; stainless steel
    Compression Ratio:
    9.6:1
    Rocker Arms (P/N 12361323):
    Aluminum roller style
    Rocker Arm Ratio:
    1.7:1
    Distributor (P/N 88961867):
    HEI
    Carburetor (P/N 19170095):
    850-cfm
    Water Pump (P/N 19168602):
    Aluminum, short-style
    Spark Plugs and Wires:
    Included
    Flexplate (P/N 12561217):
    14"
    Recommended Fuel:
    Premium
    Ignition Timing:
    36° @4,000 rpm
    Maximum Recommended rpm:
    6000


    INSTALLATION NOTES

    • Due to crate fitment, the carburetor is shipped in a separate box and needs to be installed by an engine installer
    • Clutch linkage boss is now drilled and tapped. When using cast-iron exhaust manifolds, lower head bolts may need to be replaced with bolts with shorter heads for clearance
    • Requires addition of starter and fuel pump (not included)
    • Gen VI tall-deck block has machined mechanical fuel pump boss
    • Comes with a 14" automatic transmission flexplate. Requires internally balanced flywheel for manual transmission applications
    • Designed for pre-1976 street vehicles or any off-road vehicle
    • Not intended for marine applications
    • You do have a strong transmission and rear axle, don’t you?
  • Condition: New
  • Replaces: 12498793, 19201333
  • Sold In Quantity: 1
